HZSL高效環保型模塊式制砂樓HZSL efficient environment friendly modular sand making system 一、產品概述 Abstract 　　我公司與德國著名礦山破碎企業進行國際合作，共同推進機制砂裝備技術向“高”、“精”、“尖”方向發展，引領全球制砂技術新變革。 Our company carry out international cooperation with German famous mining enterprises and we jointly promote the mechanism of sand equipment technology to "high", "pure", "tip" direction, which is the new sand technology to lead the global system. HZSL高效環保型制砂樓系統所使用的原料不僅僅是人工開采的巖石和碎石，還可以采用廉價的各種礦山尾料、廢料、建筑垃圾等作為原料加工成優質的機制砂，不僅解決了尾料、廢料、建筑垃圾不當處理帶來的環境問題，還可以變廢為寶，具有顯著的經濟環境效益。 The material of the HZSL machine needs are not only the stone mined by people,but also can use the leftover material, waste and construction waste.In this way,we can change the waste into the sand,which solve the environmental problem and have a remarkable economic environmental benefits. HZSL環保型樓式制砂系統專利核心為ZS系列高效離心沖擊式制砂機和篩分模塊，及選粉、除塵裝備組成返回式閉路系統，大幅度的增產了原來難以生產的0.6～0.15mm粒度范圍的砂，粒形可與天然砂相媲美，細度模數可在2.5～3.0之間，含粉量在5-15%之間自由簡單地調節，并且通過加濕器可以設定適當?shù)暮剩乐箵P(yáng)塵以及粒度不均。 The HZSL efficient environment friendly modular sand making system use our patent core ZS series centrifugal impact sand making machine and screening modules.And the system contains choosing powder,~,the fineness modulus is in 2.5~,preventing the dust and uneven grain size. 二、優勢特點Advantage （1）主機采用中德技術ZS系列高效離心沖擊式制砂機，效率高，投資低； The system use the sino-german technology ZS series high efficient centrifugal impactor sand making machine, high efficiency, low investment. （2）顆粒形狀為立方多棱體，咬合性好，有效提高混凝土強度； Particle shape is multi cubic body, good occlusion, effectively improve the strength of concrete. （3）系統電耗低（能耗降低50%左右），高產能（生產能力提高一倍）； 　　 Low system power consumption (energy consumption reduced by 50% or so), high capacity production capacity (double). （4）粒度數分布均勻，級配連續、穩定； The granularity distribution is uniform, gradation is continuous and stable. （5）因其為線性級配，故較之天然沙可每方C30節省水泥30-70Kg； For the linear grading, the sand can save 30-70 kg per cubic meter for C30 cement than natural sand. （6）石粉含量在5-15%之間可控； Stone powder can be controlled between 5-15%. 　　(7)細度模數穩定在之間可調； 　（8）粉塵零排放，低噪音、無振動； Dust zero emissions, low noise, no vibration. （9）占地面積小，集約化設計，模塊化組裝、靈活性強，適應各種物料的制砂和整形； Cover an area smaller, intensive design, modular assembly, flexibility is strong, adapt to sand making and shaping for all kinds materials. （10）ZS系列高效離心沖擊式制砂機采用中德技術雙腔型設計，篩分集成空氣篩分和干法篩分技術，大幅度提升篩分效率，同時有效降低堵篩故障;耐磨件采用高強合金，使用壽命大幅延長，有效降低停機檢修時間。 ZS series high efficient centrifugal impact sand making machine adopts double cavity sino-german technology design.The screening system integrates the air screening and dry screening technology,which has a higher efficiency.At the same time,it also reduces the problem of screen stoppage.The wear-resistant parts uses the high strength alloy,which pro-long the using life and efficiently reducing the time for stop and recondition. （11）高環保標準，整個系統采用全封閉輸送、生產、和負壓除塵設計，保證生產無污水，無淤泥，無粉塵以及噪音排放完整符合國家環保要求； High environmental standards, the whole system adopts closed transportation, production, and the design of negative pressure dust removal, guaranteeing the production without water, no sludge, no dust and noise emissions fully comply with national environmental requirements. 三、工作原理Working principle HZSL環保型樓式制砂系統包含ZS系列高效離心沖擊式制砂機、分級篩分模塊、濕度調配模塊、環保除塵器模塊、集中控制系統、鋼架結構等設備和模塊，是一套完整的干式制砂生產系統。 HZSL environment-friendly building sand making system contains ZS series high efficient centrifugal impact sand machine, sizing screen module, humidity deployment module, environmental protection filter module, centralized control system, steel structure and other modules of equipment,which is a set of complete system of dry sand production system. 將5-100mm的原料（可以是石屑、瓜米石等廉價易得的原料）經過ZS系列高效離心沖擊式制砂機破碎整型后，在分級篩分和除塵模塊作用下分成三路：石粉、返料和準成品砂。石粉通過除塵模塊后統一儲存在粉礦倉中，準成品砂進入拌濕器經加濕攪拌后完成加工過程。 原料經過HZSL系統合理高效的加工處理后，產出級配合理、粒型圓潤、含粉量可控的精品機制砂，以及干燥潔凈、可進行統一回收利用的精品石粉（根據原料決定可應用范圍）。 After the 5-100mm materials（include stone chips, wasted stone and other cheap material) are shaped by ZS series sand making machine,the material will be parted into three by the screen system,Powder sand,,and it make the sand have shape of reasonable gradation, fruity, controllable powder content.And the produced powder is dry clean, can be recycled uniformly(Determined according to the raw material).
